Built-in counter depth bottom freezer refrigerator- Left hinge door (picture shown is right hinge)

Built-in capable

• Front-breathing design allows fully integrated installation

Stainless steel doors

• Professional look in high quality stainless steel, with a unique curve to add a modern touch to any kitchen

Bottom freezer

• Convenient design keeps all refrigerated storage at eye level for easier use

Digital thermostats

• Separate digital controls let you adjust the refrigerator and freezer section, with a digital display for added convenience

Adaptive intelligent technology

• Innovative sensor technology allows the unit to adjust to your habits, reading your patterns to manage the temperature based on the frequency of door openings and grocery loading

Icemaker

• Factory installed icemaker ensures a steady supply of ice, eliminating the need to maintain cumbersome ice trays

Adjustable glass shelves

• Rearrange your refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up

Adjustable door storage

• Three door racks can be adjusted in height to accommodate a variety of sizes

Wine shelf

• Store bottles safely on an adjustable scalloped steel rack

Humidity controlled crisper

• Large crisper drawer allows you to ensure the optimum storage of fruits and vegetables

ZeroZone deli drawer

• Slide-out drawer allows you to store meats and other deli items at a slightly colder temperature for long-lasting freshness

Multibox storage container

• Removable container with a silicone lid and air-tight seal offers a convenient way to store smaller food items with a strong odor, such as blue-vein cheeses or onions

Removable transparent freezer drawers

• Unique freezer design keeps the cold inside, even when the door is opened

Interior LED refrigerator light

• Automatically illuminates when you open the door

No-frost operation

• Frost-free freezer section and automatic defrost refrigerator offer low maintenance operation

Open door alarm

• Audible alarm will sound if the refrigerator door is left ajar for over one minute

High temperature alarm

• Audible alarm will sound if the temperature in the refrigerator or freezer compartment is too high

Power failure alarm

• If the temperature exceeds acceptable levels due to power failure, an audible alarm will sound

LED visual alarms

• All alarms are both audible and visual, with lamps in the control panel that will illuminate when the alarm is sounded

Intensive cooling & freezing function

• Allows you to rapidly cool the refrigerator or freezer section, ideal for bringing newly loaded groceries to a safer storage temperature

Child lock

• Temperature controls include a locking function to prevent accidental setting changes

Factory reversible door swing

• Unit ships RHD unless ordered reversed in our factory. The doors are not user-reversible

Fully finished platinum cabinet

• Allows the unit to be used freestanding

100% CFC free

• Environmentally friendly design without ozone-damaging chemicals

Exterior
PNLRH Stainless steel panel installed on right side to cover FFBF181ES cabinet	PNLLH Stainless steel panel installed on left side to cover FFBF181ES cabinet

Overview
Height of Cabinet	78.75" (200 cm)
Height to Hinge Cap	79.25" (201 cm)
Width	23.63" (60 cm)
Width with Door Open	24.63" (63 cm)
Depth	25.25" (64 cm)
Depth with Handle	27.25" (69 cm)
Depth with door at 90°	47.0" (119 cm)
Capacity	12.8 cu.ft. (362 L)
Defrost Type	Frost-Free/Automatic
Door	Stainless Steel
Cabinet	Platinum
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Energy Usage/Year	474.0kWh/year
Amps	1.5
Voltage/Frequency	115 V AC/60 Hz
Weight	185.0 lbs. (84 kg)
Shipping Weight	210.0 lbs. (95 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years

Refrigerator-Freezer
Door Swing	RHD
Reversible	Factory Reversible
Adjustable Shelves	Yes
Interior Drawers	Yes
Drawer Qty	5
Crisper Qty	2
Crisper Finish	Transparent
Crisper Cover	Glass
Wine Bottle Shelving	Yes
Interior Light	Yes
Refrigerator - Interior Height	44.0" (112 cm)
Refrigerator - Interior Width	19.25" (49 cm)
Refrigerator - Interior Depth	17.5" (44 cm)
Refrigerator - Capacity	9.35 cu.ft
Refrigerator - Shelf Type	Glass and Scalloped
Refrigerator - Shelf Qty	4
Refrigerator - Full Door Shelves	4
Refrigerator - Temperature Range	34º to 46ºF
Freezer - Interior Height	24.0" (61 cm)
Freezer - Interior Width	16.5" (42 cm)
Freezer - Interior Depth	13.0" (33 cm)
Freezer - Capacity	3.46 cu.ft
Thermostat Type	Digital
Fan Type	Interior and Exterior
Refrigerant Type	R134a
Refrigerant Amount	5.11 oz.
High Side PSI	215.0
Low Side PSI	36.0
Level Legs	2
Freezer - Temperature Range	-6º to 6ºF
Compressor Step Height	8.0" (20 cm)
Compressor Step Width	16.5" (42 cm)
Compressor Step Depth	5.0" (13 cm)
