Dual Fuel Range, 30", 4 Burners

• Sealed Dual Flow Burners™ deliver cooktop power up to 22,500 BTU (NG models) for seriously fast boiling right down to a precise 140°F full surface simmer with the gentlest of flames.

• Precise control across high and low settings is delivered through the halo-illuminated cooktop dials. The ovens have true convection and electronic oven control for precise and consistent temperatures.

• The Dual Fuel Range broiler provides an even heat that covers a very large surface area — perfect for browning a fully loaded oven tray.

• The Dual Fuel Range oven has a self-cleaning function and removable side racks. The cooktop has sealed burners and an encapsulated cooking surface with a commercial-style stainless steel finish.

• Control dials have halo-illumination glowing white – heating up; orange – temperature reached; red – self-cleaning mode. The oven is illuminated by two powerful incandescent lights.

• The cooktop is designed for easy access to any burner with grates you can smoothly slide pots across. The oven is large enough to hold full size baking sheets.

Auto re-ignition system
Auto re-ignition system	true

Bake
Bake	true

Bake power
Bake power	3500

Broil
Broil	true

Broil pan
Broil pan	true

Clean
Clean	true

Concealed element
Concealed element	true

Convection bake
Convection bake	true

Convection broil
Convection broil	true

Depth
Depth	29 1/8"

Electric circuit
Electric circuit	4 wire

Electronic oven control
Electronic oven control	true

Fitting and pipe
Fitting and pipe	½ NPT, min. ?" Ø flex line

Full extension telescopic sliding shelves
Full extension telescopic sliding shelves	true

Height
Height	35 3/4 - 36 3/4"

Main oven - True convection power
Main oven - True convection power	2500W

Maximum burner power
Maximum burner power	19000 BTU

Metal illuminated dials
Metal illuminated dials	true

Number of functions
Number of functions	6

Power back left
Power back left	13000BTU

Power back right
Power back right	13000BTU

Power front left
Power front left	19000BTU

Power front right
Power front right	15000BTU

Pyrolytic self-clean
Pyrolytic self-clean	true

Rated current
Rated current	30A

Sealed range top
Sealed range top	true

Shelf positions (main oven)
Shelf positions (main oven)	5

Square handle option
Square handle option	AH-R30

Supply frequency
Supply frequency	60Hz

Supply Pressure (LPG)
Supply Pressure (LPG)	11" to 14" W.C

Total capacity (main oven)
Total capacity (main oven)	4L

Total cooktop power
Total cooktop power	60000 BTU

True convection
True convection	true

Vent trim included
Vent trim included	true

Width
Width	29 7/8"

• Service & Warranty

• User Guide

• Installation Guide

• Service & Warranty

• User Guide EN

• Installation Guide EN / Guide d'installation FR

• QRG

Extended warranties can save you hundreds, sometimes even thousands of dollars in unexpected repairs. You can contact us, or visit our store for additional details.

Let our team co-ordinate professional delivery and installation on your new purchase. Some restrictions may apply.
