True frost-free forced air cooling for optimum performance

Frost-free operation

• No-frost convenience eliminates the need to manually defrost the unit

Built-in capable

• Make the best use of space by installing your freezer under the counter and flush with other cabinets

Panel-ready door

• Integrated stainless steel door frame accepts full overlay panels, allowing you to customize the refrigerator door or blend it into your cabinetry design; panel size

Digital thermostat

• Electronic controls offer easy and intuitive temperature management

Recessed LED light

• Elegant lighting with an on/off switch located on the control panel

Adjustable shelves

• Rearrange your freezer space to accommodate all shapes and sizes or remove shelves for a simple clean-up

High temperature alarm

• High temperature alarm sounds if the unit's interior goes out of the recommended range

Open door alarm

• Audible alarm will sound if the door is left open longer than one minute

Sabbath mode setting

• Optional setting lets you disable the lighting and alarms for up to 96 hours

Temperature memory function

• Unit will retain its last settings when power is restored in the event of power loss

Commercially approved

• ETL-S listed to NSF-7 commercial standards

Fully finished cabinet

• Allows the freezer to be used as a freestanding model

100% CFC free

• Environmentally friendly design without ozone-damaging chemicals

Exterior
SSK Stainless steel kickplate factory installed	DL2 Temperature Logger USB data logger with user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout
PH - Probe Hole Factory installed probe hole for customer supplied monitoring devices	LHD Door reversal to left hand swing
Latch Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.	DL1 Temperature Logger USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac

Freezer
Door Swing	RHD
Reversible	Factory Reversible
Interior Height	26.0" (66 cm)
Interior Width	19.0" (48 cm)
Interior Depth	16.0" (41 cm)
Shelf Type	Chrome
Shelf Qty	3
Adjustable Shelves	Yes
Thermostat Type	Digital
Interior Light	Yes
Fan Type	Interior and Exterior
Refrigerant Type	R600a
Refrigerant Amount	1.24 oz.
High Side PSI	270.0
Low Side PSI	106.0

Overview
Height of Cabinet	34.0" (86 cm)
Width	23.63" (60 cm)
Depth	23.5" (60 cm)
Depth with door at 90°	45.63" (116 cm)
Capacity	4.72 cu.ft. (134 L)
Defrost Type	Frost-Free
Door	Panel-Ready
Cabinet	White
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Sanitation	ETL-S
Energy Usage/Year	390.0kWh/year
Amps	0.8
Voltage/Frequency	115 V AC/60 Hz
Weight	88.0 lbs. (40 kg)
Shipping Weight	98.0 lbs. (44 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
